Anti-Mouse CD45 (Clone I3/2.3) – Purified in vivo GOLD™ Functional Grade

Anti-Mouse CD45 (Clone I3/2.3) – Purified in vivo GOLD™ Functional Grade

Product No.: C2843

[product_table name="All Top" skus="C2843"]

- -
- -
Clone
I3/2.3
Target
CD45
Formats AvailableView All
Product Type
Monoclonal Antibody
Alternate Names
T200, Ly-5, LCA
Isotype
Rat IgG2b κ
Applications
FC
,
IHC FF
,
IHC FFPE
,
in vivo
,
WB

- -
- -
Select Product Size

Data

- -
- -

Antibody Details

Product Details

Reactive Species
Mouse
Host Species
Rat
Recommended Isotype Controls
Recommended Dilution Buffer
Immunogen
Mouse lymphoma cell line
Product Concentration
≥ 5.0 mg/ml
Endotoxin Level
< 1.0 EU/mg as determined by the LAL method
Purity
≥95% monomer by analytical SEC
>95% by SDS Page
Formulation
This monoclonal antibody is aseptically packaged and formulated in 0.01 M phosphate buffered saline (150 mM NaCl) PBS pH 7.2 - 7.4 with no carrier protein, potassium, calcium or preservatives added. Due to inherent biochemical properties of antibodies, certain products may be prone to precipitation over time. Precipitation may be removed by aseptic centrifugation and/or filtration.
Product Preparation
Functional grade preclinical antibodies are manufactured in an animal free facility using in vitro cell culture techniques and are purified by a multi-step process including the use of protein A or G to assure extremely low levels of endotoxins, leachable protein A or aggregates.
Storage and Handling
Functional grade preclinical antibodies may be stored sterile as received at 2-8°C for up to one month. For longer term storage, aseptically aliquot in working volumes without diluting and store at ≤ -70°C. Avoid Repeated Freeze Thaw Cycles.
Country of Origin
USA
Shipping
Next Day 2-8°C
Applications and Recommended Usage?
Quality Tested by Leinco
FC The suggested concentration for this I3/2.3 antibody for staining cells in flow cytometry is ≤ 0.125 μg per 106 cells in a volume of 100 μl. Titration of the reagent is recommended for optimal performance for each application.
WB The suggested concentration for this I3/2.3 antibody for use in western blotting is 1-10 μg/ml.
Additional Applications Reported In Literature ?
IHC (Frozen)
IHC (Paraffin)
Each investigator should determine their own optimal working dilution for specific applications. See directions on lot specific datasheets, as information may periodically change.

Description

Description

Specificity
Clone I3/2.3 recognizes an epitope on mouse CD45.
Background
CD45 is a 180-240kD glycoprotein member of the protein tyrosine phosphatase (PTP) family known for its involvement in regulating a variety of cellular processes including cell growth, differentiation, mitotic cycle, and oncogenic transformation. CD45 and its isoforms are vital regulators of T- and B-cell antigen receptor signaling. CD45 functions through its extracellular domain or through its cytoplasmic domain, and serves as a negative regulator of cytokine receptor signaling via JAK kinase supression. The large extracellular domain is highly glycosylated, and its multiple isoforms allow extensive variation in the structure of its side chains. CD45 isoforms show cell-type and differentiation-stage specific expression that can be used as markers that identify and distinguish between different types of immune cells. CD45R is an isoform of CD45 with a molecular weight of 220 kD. CD45R contains all three possible exons (A, B, and C); making it the longest protein generated from alternative splicing with a migration at 200 kD when isolated from T cells. Furthermore, B cells express CD45R with heavier glycosylation, bringing the molecular weight to 220 kD, hence the name B220. Notably, B220 expression is not only restricted to B cells and may also be expressed on activated T cells, on a subset of dendritic cells, and on other antigen-presenting cells. Additionally, activated and memory T lymphocytes express CD45RO which facilitates T cell activation. CD45RO lacks all three possible exons (A, B, and C), making it the shortest CD45 isoform.
Antigen Distribution
CD45 is expressed on all hematopoietic cells other than mature erythrocytes and platelets.
Ligand/Receptor
Galectin-1, CD2, CD3, CD4, TCR, CD22, Thy-1
Function
Phosphatase, T and B cell activation
NCBI Gene Bank ID
Research Area
Cell Biology
.
Immunology
.
Inhibitory Molecules
.
Neuroscience
.
Neuroscience Cell Markers
.
Stem Cell

Leinco Antibody Advisor

Powered by AI: AI is experimental and still learning how to provide the best assistance. It may occasionally generate incorrect or incomplete responses. Please do not rely solely on its recommendations when making purchasing decisions or designing experiments.

Clone I3/2.3 is a rat monoclonal antibody directed against mouse CD45 that is commonly used in in vivo mouse studies to label, deplete, or track hematopoietic (immune) cells, as CD45 is expressed on all leukocytes except mature red cells.

In vivo applications of clone I3/2.3 include:

  • Depletion of hematopoietic cells: By administering the antibody in vivo, researchers can deplete specific populations of CD45? cells, which allows investigation of immune function or cell lineage contributions in murine experimental models.
  • In vivo cell labeling: Administering clone I3/2.3 allows for discrimination between cells accessible to the bloodstream and resident cells, particularly in trafficking or tissue localization studies.
  • Functional blocking: Antibody binding to CD45 can modulate immune cell function and signaling pathways, affecting T- or B-cell signaling, and cytokine receptor signaling, which is useful in mechanistic immunology research.

Experimental contexts:

  • Cell tracking and fate mapping: In vivo labeling allows researchers to distinguish between tissue-resident and circulating immune cells in endpoint analysis (e.g., via flow cytometry using I3/2.3 for in vivo labeling and a non-competing clone for ex vivo staining).
  • Immunophenotyping: Because I3/2.3 recognizes all isoforms of CD45, it is used as a pan-leukocyte marker to profile hematopoietic cells in tissues or blood, including in in vivo settings.
  • Immunodepletion or modulation: High-purity or low-endotoxin forms of the antibody are used for in vivo depletion or manipulation of immune populations and signaling.

Conjugation and detection formats:

  • Clone I3/2.3 is available unconjugated or conjugated (e.g., to PE for flow cytometry), and in low-endotoxin, in vivo-ready formulations.

Summary of use:
In vivo, clone I3/2.3 antibody is injected into mice primarily for immunological studies involving identification, depletion, or tracking of leukocytes based on the expression of CD45—a hallmark of nearly all immune cells—making it a versatile tool in immunology, cell trafficking, and depletion studies in mouse models.

The correct storage temperature for the sterile packaged clone I3/2.3 (anti-mouse CD45 antibody) is 2–8°C, and it should not be frozen.

This is specified by multiple sources describing this antibody clone:

  • One supplier notes: "This purified antibody is stable when stored at 2-8°C. Do not freeze".
  • Another product specification instructs: "Store undiluted at 4°C and protected from prolonged exposure to light".

Additional details:

  • Do not freeze: Freezing may compromise the structural integrity or efficacy of monoclonal antibodies, including clone I3/2.3.
  • Light protection: Some conjugated forms (e.g., fluorochrome-labeled) should be protected from light to avoid photobleaching, as specified for some vendors.
  • Stability: When maintained at 2–8°C, the antibody remains stable over its recommended shelf-life by the manufacturer.

Always confirm with your product’s accompanying datasheet for any additional storage requirements specific to your formulation.

Commonly used antibodies or proteins paired with I3/2.3 (an anti-mouse CD45 antibody) in the literature are typically those that allow for the identification and characterization of specific immune cell subsets and their states. The following are among the most frequently used:

  • CD3 (T cell marker)
  • CD19 or B220/CD45R (B cell markers; sometimes specifically mentioned as B220, a CD45 isoform)
  • CD11b (myeloid/monocyte marker)
  • CD4 and CD8 (T cell subset markers)
  • Gr-1 (granulocyte marker)
  • Ter119 (erythroid cell marker)
  • F4/80 (macrophage marker)

I3/2.3 labels all leukocytes except erythrocytes by targeting a framework epitope on all CD45 isoforms. In practice, it is most commonly used in combination with the markers listed above for multi-parametric flow cytometry or immunohistochemistry, enabling researchers to distinguish and analyze distinct cell populations within mouse hematopoietic tissues.

  • When identifying lymphoid populations, anti-CD3 (T cells) and anti-B220/CD19 (B cells) are standard partners.
  • For myeloid and granulocyte populations, anti-CD11b and anti-Gr-1 are often used together.
  • CD4 and CD8 are always included in panels for distinguishing T cell subsets, frequently in combination with anti-CD3.
  • Ter119 is commonly used for gating out erythroid cells, which do not express CD45.

Further, isotype controls matched to rat IgG2b (the isotype of I3/2.3) are often included to assess non-specific binding.

This antibody is utilized in panels to comprehensively characterize the immune landscape in mouse models, allowing exclusion (live/dead, Ter119, non-leukocytes) or inclusion (CD45+, cell type markers) of relevant populations depending on the study focus.

Clone I3/2.3 is a rat monoclonal antibody widely used to identify and study mouse CD45, a key leukocyte common antigen involved in immune cell signaling. The principal findings from scientific literature citing clone I3/2.3 are:

  • Recognition of Mouse CD45: Clone I3/2.3 specifically recognizes an epitope on mouse CD45, a family of proteins critical for regulating T- and B-cell activation, growth, and differentiation.

  • CD45 Isoforms as Immune Markers: CD45 has multiple isoforms due to alternative splicing, enabling researchers to distinguish between various immune cell types and their differentiation stages using I3/2.3. For example, B220 is a heavily glycosylated isoform found on B cells.

  • Widespread Use in Immune Cell Detection: I3/2.3 is the standard antibody for flow cytometry, immunohistochemistry, and functional studies to label and track mouse leukocytes in models of immunity, inflammation, and disease. Studies have applied I3/2.3 to:

    • Discriminate murine dendritic cell subsets and analyze their CD45 isoform expression.
    • Assess immune cell infiltration and function in autoimmune models like EAE and type 1 diabetes.
    • Quantify and sort splenocytes and tumor-infiltrating lymphocytes in oncology and transplantation studies.
  • Functional Relevance in Research:

    • In diabetic mouse models, I3/2.3 enabled tracking of immune cell infiltration in pancreatic islets and monitoring the impact of therapeutic interventions on T-cell and macrophage activity.
    • In neuroscience, I3/2.3 staining has been used to study microglia and macrophage function in neuroinflammation and multiple sclerosis models.
    • In basic immunology, foundational work mapped the immunogen for I3/2.3 to T200, later identified as mouse CD45.
  • Mechanistic Insights: CD45, as detected by I3/2.3, is central to modulating antigen receptor signaling and, by extension, immune cell responsiveness and autoimmunity susceptibility.

  • Technical Citations: Over 10 peer-reviewed publications utilize I3/2.3 for immune phenotyping, often highlighting its reliability and specificity.

In summary, clone I3/2.3 is a cornerstone tool in mouse immunology for identifying and analyzing CD45-expressing leukocytes, enabling advances in both fundamental research and disease modeling.

References & Citations

Flow Cytometry
IHC FF
IHC FFPE
in vivo Protocol
General Western Blot Protocol

Certificate of Analysis

- -
- -
Disclaimer AlertProducts are for research use only. Not for use in diagnostic or therapeutic procedures.
