Anti-Mouse CD80 [Clone 16-10A1] — Purified in vivo GOLD™ Functional Grade

Anti-Mouse CD80 [Clone 16-10A1] — Purified in vivo GOLD™ Functional Grade

Product No.: C2045

[product_table name="All Top" skus="C2045"]

- -
- -
Clone
16-10A1
Target
B7-1
Formats AvailableView All
Product Type
Monoclonal Antibody
Alternate Names
B7-1, B71, Ly53, TSA1, Cd28l, Ly-53, MIC17
Isotype
IgG
Applications
B
,
CyTOF®
,
in vivo
,
IP
,
WB

- -
- -
Select Product Size

Data

- -
- -

Antibody Details

Product Details

Reactive Species
Mouse
Host Species
Armenian Hamster
Recommended Dilution Buffer
Immunogen
Purified Recombinant Mouse CD80 (>98%)
Product Concentration
≥ 5.0 mg/ml
Endotoxin Level
< 1.0 EU/mg as determined by the LAL method
Purity
≥95% monomer by analytical SEC
>95% by SDS Page
Formulation
This monoclonal antibody is aseptically packaged and formulated in 0.01 M phosphate buffered saline (150 mM NaCl) PBS pH 7.2 - 7.4 with no carrier protein, potassium, calcium or preservatives added. Due to inherent biochemical properties of antibodies, certain products may be prone to precipitation over time. Precipitation may be removed by aseptic centrifugation and/or filtration.
Product Preparation
Functional grade preclinical antibodies are manufactured in an animal free facility using in vitro cell culture techniques and are purified by a multi-step process including the use of protein A or G to assure extremely low levels of endotoxins, leachable protein A or aggregates.
Storage and Handling
Functional grade preclinical antibodies may be stored sterile as received at 2-8°C for up to one month. For longer term storage, aseptically aliquot in working volumes without diluting and store at ≤ -70°C. Avoid Repeated Freeze Thaw Cycles.
Country of Origin
USA
Shipping
Next Day 2-8°C
Additional Applications Reported In Literature ?
CyTOF®
Each investigator should determine their own optimal working dilution for specific applications. See directions on lot specific datasheets, as information may periodically change.

Description

Description

Specificity
Clone 16-10A1 recognizes an epitope on mouse CD80.
Background
CD80 is a highly glycosylated 60 kD protein that is part of the Ig superfamily and is significantly involved in immune cell activation in response to pathogens. CD80 is closely related to, and works in tandem with CD86 (B7-2) to prime T- cells. CD80 binds to CTLA-4 to deliver an inhibitory signal to T cells. The ligation of CD28 on T cells with CD80 and CD86 on APCs co-stimulates T cells resulting in enhanced cell activation, proliferation, and cytokine production. It is thought that CD80 interacts with a ligand on Natural Killer cells, activating the Natural Killer cell-mediated cell death of the CD80 carrier. The activation of Natural Killer cell-mediated death via CD80 interactions has potential as a possible cancer immunotherapy through the induction of CD80 expression on tumor cells.
Antigen Distribution
CD80 is expressed on activated B cells, monocytes/macrophages, and dendritic cells.
Ligand/Receptor
CD28 (stimulatory), CD152(CTLA4) (inhibitory)
Function
T cell costimulation
PubMed
NCBI Gene Bank ID
Research Area
Cell Biology
.
Costimulatory Molecules
.
Immunology
.
Neuroscience
.
Neuroscience Cell Markers

Leinco Antibody Advisor

Powered by AI: AI is experimental and still learning how to provide the best assistance. It may occasionally generate incorrect or incomplete responses. Please do not rely solely on its recommendations when making purchasing decisions or designing experiments.

Clone 16-10A1 is an anti-mouse CD80 (B7-1) monoclonal antibody widely used in in vivo mouse studies to block the costimulatory function of CD80, thereby modulating T cell activation and immune responses.

Key uses in in vivo mouse studies:

  • Blockade of CD80-mediated costimulation: 16-10A1 prevents the interaction between CD80 and its receptors, CD28 (which stimulates T cells) and CTLA-4 (which inhibits T cells). This effectively blocks T cell activation signals mediated by CD80, allowing researchers to interrogate the role of CD80 in immunity, tolerance, and autoimmunity.
  • Selective action: It specifically blocks CD80 without affecting the activity of CD86 (B7-2), the other main costimulatory molecule.
  • In vivo applications: The unconjugated form of 16-10A1 is typically used for systemic administration in mice to block CD80 function in disease models, such as autoimmunity, infection, transplantation tolerance, and tumor immunity.
  • Reported as In Vivo Ready/Low Endotoxin: Preparations marketed as "in vivo ready" or "low endotoxin" are specifically purified and quality-controlled for safe injection into mice.

Mechanistic details:

  • CD80 Expression: Found on activated B cells, activated T cells, macrophages, and dendritic cells in mice.
  • Administration: The antibody is typically injected intraperitoneally or intravenously at doses specified by experimental needs to achieve systemic blockade.

Other uses:

  • While 16-10A1 is also used for flow cytometry and immunofluorescence in its conjugated forms, in in vivo studies the primary application is functional blockade, not detection.

Summary:
Clone 16-10A1 is used in vivo to experimentally block CD80-mediated T cell co-stimulation in mice, thus enabling investigation of CD80's immunological roles and its potential as a therapeutic target.

The correct storage temperature for the sterile packaged clone 16-10A1 (anti-CD80 monoclonal antibody) is 2–8°C (standard refrigerator temperature), protected from light, and it should not be frozen.

Most suppliers and technical datasheets specify this temperature range for both short-term and long-term storage to maintain product stability and functionality. Key guidance includes:

  • Store at 2–8°C (refrigerator; typically equivalent to 4°C is acceptable within this range).
  • Protect from prolonged exposure to light, as fluorochrome-conjugated antibodies (such as PE or FITC conjugates) are light-sensitive.
  • Do not freeze; freezing can damage the antibody or affect its binding capability.

This guidance applies specifically to the sterile, ready-to-use, or undiluted antibody reagent version of clone 16-10A1, including common commercial formats. If the product is in a different formulation (e.g., lyophilized powder), additional instructions from the product datasheet should be followed.

The antibody 16-10A1 targets CD80 (B7-1), a co-stimulatory molecule involved in T cell activation. Commonly, antibodies or proteins used alongside 16-10A1 in the literature are those that modulate related immune pathways, particularly those associated with T cell signaling and co-stimulation.

Key antibodies and proteins commonly used with 16-10A1 include:

  • Anti-CD86 (B7-2) antibodies: CD86 is the second major co-stimulatory ligand for CD28 and CTLA-4, often examined alongside CD80 for their complementary or redundant roles in T cell activation.
  • CD28 blockade or recombinant CD28: Since CD80 and CD86 both interact with CD28, inhibitors or agonists for CD28 are frequently used in combination to dissect signaling pathways.
  • CTLA-4 antibodies or CTLA-4-Ig fusion protein: Because CD80 binds CTLA-4 as well, blocking or modulating this interaction is common in immunological experiments focused on co-inhibitory signals.
  • T cell surface markers (CD3, CD4, CD8): When studying T cell activation, antibodies targeting these core markers are routinely included to identify and sort T cell subpopulations.
  • MHC class II antibodies: For functional antigen presentation studies that involve co-stimulation, antibodies blocking MHC class II are often used with 16-10A1.
  • Other immune checkpoint molecules (PD-1, PD-L1): Frequently included in studies mapping immune regulatory networks in disease or therapy contexts.

Supporting context:

  • In flow cytometry and functional blocking studies, anti-CD86 (clone GL1 or PO3) is typically paired with 16-10A1 to block both B7 ligands and assess their combined influence on T cell activation.
  • In inhibition experiments, CTLA-4-Ig fusion proteins are used to block both CD80 and CD86 by outcompeting CD28 binding.
  • Literature often includes combinations of 16-10A1 with antibodies for CD28 and CTLA-4 to parse out the contributions of each interaction to immune response outcomes.

These combinations are frequently observed in publications studying T cell costimulation, immune tolerance, transplant models, and cancer immunotherapy.

Clone 16-10A1 is a widely used monoclonal antibody targeting mouse CD80 (B7-1), primarily employed to study immune costimulation, T cell activation, and immune checkpoint biology in murine models. The key findings from citations of 16-10A1 in scientific literature are as follows:

  • Specificity and Mechanism: 16-10A1 specifically binds to mouse CD80 and blocks its costimulatory function, preventing CD80 from interacting with its ligands CD28 (which stimulates T cells) and CTLA-4 (which inhibits T cells). Importantly, 16-10A1 does not block CD86, a closely related costimulatory molecule.

  • Experimental Applications:

    • Used to block CD80 in vivo, allowing researchers to distinguish the unique roles of CD80 versus CD86 in immune responses such as T cell activation, autoimmunity, and tumor immunology.
    • Commonly applied in flow cytometry, in vivo functional blocking, and immunophenotyping protocols of murine tissues (e.g., spleen, lymph node, tumor microenvironment).
  • Cellular and Tissue Distribution: CD80 is expressed on activated B cells, activated T cells, monocytes, macrophages, and dendritic cells. 16-10A1 is used to selectively stain and block CD80 on these populations.

  • Cross-Species Use and Limitations: While 16-10A1 is essential for mouse studies, its cross-reactivity in other species (e.g., dog, rat, human) is variable and can lead to inconsistent results. For instance, in dogs, 16-10A1 has been reported to bind to neutrophils and monocytes in both healthy and leukemic (AML) cases—results that differ markedly from findings in mice and from other CD80 clones. This suggests potential cross-reactivity with other B7 family molecules or antigenic differences, prompting the need for caution and additional validation in non-murine species.

  • Research Insights Uncovered by 16-10A1 Use:

    • Demonstrated the major role of CD80 in the costimulation and regulation of T cell responses, including in models of infection, tumor immunity, and autoimmunity.
    • Dissection of immune checkpoint pathways: The antibody is often used in conjunction with other inhibitors (such as anti-CD86 or anti-PD-L1) to parse out the individual contributions of costimulatory/inhibitory signals in vivo.
    • Revealed differences in antigen detection depending on the clone used, sample type, species, and technical conditions—emphasizing the importance of proper controls and antibody validation in immunological experiments.
  • Notable Citation Trends: Clone 16-10A1 is routinely cited in foundational and applied studies on the immunobiology of T cell responses, checkpoint blockade, and immune regulation in murine models, particularly in cancer immunotherapy and transplantation literature.

In summary, clone 16-10A1 is a gold standard reagent for blocking and detecting murine CD80, critical for dissecting T cell costimulation and checkpoint regulation, but its use outside standard murine systems requires rigorous validation due to potential cross-reactivity and species differences.

References & Citations

1.) Gubin, M. et al. (2018) Cell. 175(4):1014–1030.e19 Journal Link
B
CyTOF®
in vivo Protocol
Immunoprecipitation Protocol
General Western Blot Protocol

Certificate of Analysis

- -
- -
Disclaimer AlertProducts are for research use only. Not for use in diagnostic or therapeutic procedures.
